Ethernet Remote I/O ioLogik E2212

Smart I/O controller with 8DI, 8DO & 4DIO, Click&Go; Front-end intelligence

$0.00
9% Tax included Shipping calculated at checkout.

Moxa’s ioLogik E2200 Series Ethernet Remote I/O is a PC-based data acquisition and control device that uses proactive, event-based reporting to control I/O devices and features the Click&Go programming interface. Unlike traditional PLCs, which are passive and must poll for data, Moxa’s ioLogik E2200 Series will, when paired with our MX-AOPC UA Server, communicate with SCADA systems using active messaging that is pushed to the server only when state changes or configured events occur. Additionally, the ioLogik E2200 features SNMP for communications and control using an NMS (Network Management System), allowing IT professionals to configure the device to push I/O status reports according to configured specifications. This report-by-exception approach, which is new to PC-based monitoring, requires far less bandwidth than traditional polling methods.



Moxa ioLogik E2212 Specifications

Inputs and Outputs
Digital Inputs: 8 channels
Digital Outputs: 8 channels
Configurable DIOs: 4 channels
Isolation: 3k VDC or 2k Vrms


Digital Input
Sensor Type: Wet Contact (NPN or PNP) and Dry Contact
I/O Mode: DI or Event Counter
Dry Contact:
• On: short to GND
• Off: open
Wet Contact (DI to GND):
• On: 0 to 3 VDC
• OFF: 10 to 30 VDC
Common Type: 6 points per COM
Counter Frequency: 900 Hz
Digital Filtering Time Interval: Software Configurable


Digital Output
Type: Sink
I/O Mode: DO or Pulse Output
Pulse Output Frequency: 1 kHz
Over-Voltage Protection: 45 VDC
Over-Current Protection: 2.6 A (4 channels @ 650 mA)
Over-Temperature Shutdown: 175°C (min.)
DIO Output Leakage Current: 4.0 mA @ 24 VDC
Current Rating: 200 mA per channel


Power Requirements
Input Voltage: 12 to 36 VDC
Input Current: 136 mA @ 24 VDC

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
Moxa ioLogik E2000 series
