Moxa

PoE Splitter SPL-24

Splits power and data from PoE equipment with short-circuit protection and smart auto disconnect. DNV and industrial certified

Datasheet
SGD $0.00
9% Tax included Shipping calculated at checkout.

- IEEE802.3af compliance
- Power/data split from PoE lines using either spare-pairs or data pairs
- Supports up to 12.95 W at 24 VDC
- Support for up to 15.4 watts per PoE port
- Short circuit protection
- Auto disconnect in the event of over/under voltage
- Power consumption detection and classification



Moxa’s SPL-24 PoE splitters perform the role of powered devices (PDs) and split power from the injector to Ethernet devices. When using Moxa’s devices, power and data can be transmitted up to 100 meters (328 feet) from the power source equipment (PSE). SPL-24 is certified for maritime and industrial applications. Certifications include DNV, GL, ABS, LR, NK, IEC and more. The standard model operates from 0 to 60C. Moxa offers a wide-temperature model that operates from -40 to 75°C.

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
Moxa Industrial PoE Splitter SPL-24 - DNV Certified
Moxa

PoE Splitter SPL-24

SGD $0.00

- IEEE802.3af compliance
- Power/data split from PoE lines using either spare-pairs or data pairs
- Supports up to 12.95 W at 24 VDC
- Support for up to 15.4 watts per PoE port
- Short circuit protection
- Auto disconnect in the event of over/under voltage
- Power consumption detection and classification



Moxa’s SPL-24 PoE splitters perform the role of powered devices (PDs) and split power from the injector to Ethernet devices. When using Moxa’s devices, power and data can be transmitted up to 100 meters (328 feet) from the power source equipment (PSE). SPL-24 is certified for maritime and industrial applications. Certifications include DNV, GL, ABS, LR, NK, IEC and more. The standard model operates from 0 to 60C. Moxa offers a wide-temperature model that operates from -40 to 75°C.
