- Three 5.25”HDD and one 3.5” HDD drive bays
- ATX or redundant power supply (optional)
- Lockable front door
Height: 4U
Expansion: 20-slot
Drive Bay: 3 x 5.25” HDD drive bay, 2 x 3.5” HDD drive bay
Cooling System: 3 x 12 cm hot-swap ball-bearing fans (88 CFM/each) with a removable filter
System Board: PICMG SBCs
Axiomtek Backplane Options: ATX6022/20GP18
I/O Interface: 2 x USB, 1 x PS/2 6-pin keyboard/mouse, 1 x 0.4W speaker
Front Panel Indicators: 1 x Power, 3 x HDD
Front Panel Controls: 1 x Power on/off, 4 x System reset
Power: Hot-swap redundant or PS/2 power supply
Operating Temperature: 0°C to +40°C (+32°F to +104°F)
Dimensions: (W x D x H): 482.6 x 678.5 x 176.4 mm (19" x 26.8" x 7")
Weight (net/gross): 2.3 kg (5.07 lb)/24.6 kg (54.24 lb)
