- Three 5.25”HDD and one 3.5” HDD drive bays
- ATX or redundant power supply (optional)
- Lockable front door
Height: 4U
Expansion: 14-slot backplane
Drive Bay: 3 x 5.25” HDD drive bay, 2 x 3.5” HDD drive bay
Cooling System: 1 x 12 cm DC fan with a removable filter
System Board
TM version: ATX or Micro-ATX motherboard
TB version: PICMG 1.0 & PICMG 1.3 SBCs
Axiomtek Backplane Options: FAB100, FAB101, FAB112, FAB113, FAB114, FAB118, FAB119
I/O Interface: 2 x USB (default), 2 x USB (optional)
Front Panel Indicators: 1 x Power, 1 x HDD
Front Panel Controls: 1 x Power on/off, 1 x System reset
Power: ATX or redundant PSU
Operating Temperature: 0°C to +40°C (+32°F to +104°F)
Dimensions: (W x D x H) 479.3±1.0mm x 447.85±1.0mm x 177±1.0mm (18.87" x 18.63" x 6.97")
Weight (net/gross): 18 kg (39.68 lb)/19.5 kg (43 lb)
