Axiomtek

Edge AI Computer AIE800-904-FL

Outdoor IP67 Fanless Edge AI System with NVIDIA Jetson Xavier NX and 384 core NVIDIA Volta GPU

Datasheet
SGD $0.00
9% Tax included Shipping calculated at checkout.

- IP67-rated design, specifically for outdoor environments
- NVIDIA Jetson Xavier NX with Volta GPU architecture with 384 NVIDIA CUDA cores
- High AI computing performance for GPU accelerated processing
- Operating temperature range -30°C to +50C
- 100 to 240 VAC wide range power input with 10kV surge protection
- 4 N-jack antenna openings with water-proof design
- Features M12 lockable I/Os
- 1 IEEE 802.3at GbE PoE (30W)



Axiomtek outdoor embedded computer AIE800-904-F is powered by NVIDIA Jetson Xavier NX CPU which has a powerful 6-core NVIDIA Carmel ARM v8.2 (64-bit) processor and 384-core NVIDIA Volta GPU. AIE800-904-FL features IP67 rated chassis to protect against water and dust. It also features M12 type I/O connectors and four waterproof N-jack antenna openings for operational stability in rugged environments.



This robust embedded system features one M.2 Key B 2242 SSD socket with a high-speed PCIe 2.0 x2 NVMe interface for extensive storage needs. It also offers one GbE PoE port for IP camera video surveillance solutions including traffic flow monitoring, license plate recognition, vehicle recognition, intrusion detection and access control. TNS recommends this NVIDIA edge AI system for outdoor applications such as traffic management, city security, smart manufacturing, and more.



Axiomtek AIE800-904-FL is an excellent AI embedded system that supports one C3 USB 2.0 port, one M12 X-Code Gigabit PoE port, one M12 S-Code connector for AC power supply and one C3 HDMI port supporting full HD. The four waterproof N-jack antenna openings provide flexibility for WLAN or WWAN usage. Furthermore, the AI rugged computer has a full-size PCI Express Mini Card as well as a SIM card slot for 4G/LTE/GPRS connections. Open-source operating system Linux Ubuntu 18.04 is supported. It integrates Allxon Device Management Solutions (Allxon DMS) to provide a cost-effective and simplified device management solution with comprehensive remote management capabilities. Its flexible mounting options including wall mount and VESA mount.
