Mini ITX Motherboard MANO566

Mini-ITX SBC with LGA1700 Socket 14th/13th/12th Gen Intel Core Processor, Intel Q670E/R680E/H610E, 2 HDMI, DisplayPort++, eDP, 2 GbE LAN, and HD Audio

Datasheet
$0.00
9% Tax included Shipping calculated at checkout.

- LGA1700 12th gen Intel® Core™ i9/i7/i5/i3 processor
- Intel® H610 chipset
- 2 DDR4 SO-DIMM for up to 64GB memory
- 2 USB 3.2 Gen1 and 5 USB 2.0
- 1 2.5GbE LAN and 4 COM ports
- 1 PCIe x16, 1 M.2 Key E and 1 M.2 Key B
- 1 full-size mini-PCIe slot
- 1 SATA-600
- 12 to 24 VDC power in



Axiomtek MANO566 is a robust Mini-ITX motherboard with versatile I/O expansion capabilities. Powered by the 14th/13th/12th gen Intel® Core™ i9/i7/i5/i3 processor paired with the Intel® Q670E/R680E/H610E chipset, it delivers outstanding processing power. MANO566 ensures efficient data handling with a variety of I/O options such as four COM and eight USB ports, promoting seamless communication among diverse devices, sensors, and systems. It is suited for kiosk solutions in smart retail and industrial IoT applications, showcasing excellence in both performance and adaptability.



Axiomtek’s MANO566 maximizes performance with its two 260-pin DDR4-3200 MHz slots, supporting up to 64GB. A PCIe x16 Gen5 slot provides users with the flexibility to easily enhance visual data processing for legacy automation control devices, machine vision, and entry-level medical imaging. Additionally, the MANO566 supports an M.2 Key M 2280 slot for SATA storage modules, an M.2 Key B 3052/3042 slot for 5G modules, and an M.2 Key E 2230 slot for Wi-Fi/Bluetooth modules. In addition, it features two GbE LAN ports to ensure swift and reliable connectivity when connecting sensors for manufacturing or conducting real-time quality inspections



Axiomtek MANO566 supports the Intel UHD Graphics 700 series engine. It can handle up to four independent displays with DisplayPort++, eDP, and two HDMI interfaces, facilitating multitasking in computing workflows while delivering advanced graphics performance. Furthermore, this robust Mini-ITX board boasts various I/O functionalities, including four USB 3.2 ports, four USB 2.0 ports, two GbE LAN ports, four COM ports supporting RS-232/422/485, two SATA-600 ports, and an audio port. These comprehensive I/O interfaces not only improve inter-device connectivity but also maximize port utilization for efficient and versatile automation applications.
