Axiomtek

3.5-inch CAPA520

3.5” Embedded SBC with LGA1151Socket 9th/8th Gen Intel Core i7/i5/i3, Pentium & Celeron Processor, DisplayPort, HDMI, LVDS and 3 GbE LAN

Datasheet
$0.00
9% Tax included Shipping calculated at checkout.

- LGA1151 socket 9th/8th gen Intel CoreTM i7/i5/i3 processor
- Intel H310/Q370 chipset
- 1 DDR4 SO-DIMM for up to 16GB of memory
- 3 GbE LAN
- 1 PCI Express Mini Card slot
- Intel AMT 12 supported (optional)



Axiomtek CAPA520 features LGA1151 socket 9th/8th generation Intel Core i7/i5/i3 and Intel Celeron processors (code name: Coffee Lake) with the Intel H310 chipset (Q370 optional). The industrial-grade CAPA520 with a size of 146 mm x 104 mm features triple-display capability through HDMI, LVDS and DisplayPort interfaces, enabling multi-display applications in a limited space.



With rich I/O connectivity and great expansions, CAPA520 was designed to shorten the time to market and reduce development costs. It delivers powerful 3D and 4K graphics through the integrated Intel® UHD Graphics 630. Moreover, it can operate in a wide temperature range from -20°C to 60°C. To ensure reliable and stable operation, this 3.5-inch embedded SBC supports the Intel AMT 12 for easy remote management and monitoring and has hardware monitoring function to monitor CPU/system temperature, voltage and fan speed. This powerful embedded SBC is optimized for various industrial IoT-related applications in the embedded market, such as industrial control, machine vision, self-service terminal, digital signage, and medical imaging.
